SMC10 Smart Mitigation Cell
SMC10 is a Smart Mitigation Cell which allows controlled DC current drain to ground in the situations where AC, DC interference or telluric effect cause over protection on a cathodically protected structure.
The structure to reference value is constantly compared to the desired set value by monitoring a reference electrode. When the reference value exceeds the set value, SMC10 drains appropriate current to the ground so that the protection potential is exactly at the desired point. Variable Resistance Grounding provides precise adjustment of the drained current within a very large range. SMC10 drains AC interferences directly to ground continuously to minimize the AC influence on the protection. SMC10 can also be used to drain excessive current caused by large AC interference between Anode to Cathode connections of the CP rectifiers.
SMC10 becomes open-circuit for the DC currents when the protection potential is below the desired point and behaves in just the same manner as a normal polarization cell.
SMC10 includes an industry standard RS485 MODBUS port for connection to SCADA systems. AC, DC currents, Reference to Structure potentials can be monitored over SCADA.
Download Datasheet
Technical Specifications
Supply Voltage Range | 12- 50 VDC |
Reverse Polarity Protection | Var |
Operating Temperature Range | -20, +50C |
Continuous AC Current | 20A |
Continuous DC Current | 10A |
AC Fault Current (0.1 sec) | 500A |
Internal Impedance (AC) | 40mOhm |
Internal Impedance Range(DC) | 0.1 Ohm – 100kOhm |
Structure to Earth Treshold | 1.3V |
Analog Input | 1 Bipolar |
Analog Input Voltage Range | ±10V |
Input Impedance | 10MOhm |
Galvanic Isolation | 2500V AC 1 min |
LCD Display | 3 Lines, total 48 Characters |
Information Shown on Display | Reference to Structure Set Value, Reference to Structure DC value, Reference to Structure AC Value, Drained AC Current, Drained DC Current, Modbus ID |
Reference to Structure Voltage Adjustment Range | 800-1600mV |
Over Temperature Protection | ✓ |
Scada | RS485 Modbus RTU |
